| Model |
Delivery capacity (cc/rev) |
Max. pressure (kgf/cm²) |
Speed (rpm) |
| Max. |
Min. |
| at 1000rpm |
at 1200rpm |
at 1500rpm |
at 1800rpm |
|
PV2R1-06
|
6.2 |
7.4 |
9.3 |
11.2 |
210 |
1800 |
1200 |
|
PV2R1-08
|
8.1 |
9.4 |
12.1 |
14.6 |
210 |
1800 |
950 |
|
PV2R1-10
|
10.1 |
12.1 |
15.1 |
18.9 |
245 |
1800 |
950 |
|
PV2R1-12
|
12.2 |
14.6 |
18.3 |
21.9 |
245 |
1800 |
950 |
|
PV2R1-14
|
13.6 |
17.1 |
21.5 |
25.7 |
245 |
1800 |
950 |
|
PV2R1-17
|
16.6 |
20.5 |
25.6 |
0.7 |
245 |
1800 |
950 |
|
PV2R1-19
|
18.6 |
23 |
28.8 |
34.5 |
245 |
1800 |
950 |
|
PV2R1-23
|
22.7 |
27.9 |
34.9 |
41.9 |
245 |
1800 |
950 |
|
PV2R1-25
|
25.3 |
31.3 |
39.1 |
46.9 |
245 |
1800 |
950 |
|
PV2R1-31
|
31 |
37.3 |
46.6 |
— |
245 |
1500 |
950 |
|
PV2R2-26
|
26.2 |
31.4 |
39.3 |
47.1 |
245 |
1800 |
950 |
|
PV2R2-33
|
33 |
38.5 |
48.1 |
57.7 |
245 |
1800 |
950 |
|
PV2R2-38
|
38.2 |
45.8 |
57.3 |
68.7 |
245 |
1800 |
950 |
|
PV2R2-41
|
41.3 |
49.2 |
61.5 |
73.8 |
210 |
1800 |
950 |
|
PV2R2-47
|
47.2 |
57.8 |
71.4 |
86.7 |
245 |
1800 |
950 |
|
PV2R2-53
|
53.1 |
63.7 |
79.6 |
95.5 |
245 |
1800 |
950 |
|
PV2R2-59
|
60.2 |
72.7 |
90.3 |
108.3 |
210 |
1800 |
950 |
|
PV2R2-65
|
65.3 |
78.3 |
97.9 |
117.5 |
210 |
1800 |
950 |
|
PV2R3-60
|
60.3 |
72.3 |
90.4 |
108.5 |
210 |
1800 |
900 |
|
PV2R3-66
|
66.4 |
79.6 |
99.6 |
119.5 |
210 |
1800 |
900 |
|
PV2R3-76
|
76.3 |
91.5 |
114.4 |
137.3 |
210 |
1800 |
900 |
|
PV2R3-85
|
84.5 |
101.4 |
126.7 |
152.1 |
210 |
1800 |
900 |
|
PV2R3-88
|
88.3 |
105.9 |
132.4 |
158.9 |
210 |
1800 |
900 |
|
PV2R3-94
|
93.6 |
113.4 |
141.7 |
170.1 |
210 |
1800 |
900 |
|
PV2R3-108
|
108.2 |
129.8 |
162.3 |
194.4 |
210 |
1800 |
900 |
|
PV2R3-116
|
115.6 |
139.3 |
174.1 |
208.9 |
175 |
1800 |
900 |
|
PV2R3-126
|
125.6 |
149.5 |
186.9 |
226 |
175 |
1500 |
900 |
